XAB 32010 X TIMKEN

Name: XAB 32010 X TIMKEN
Brand: TIMKEN
SKU: 2392001B TIMKEN
Price: 86.24 PLN
Availability: OutOfStock

Dimensions

50mm

80mm

20mm

, XAB even larger assembly cut 091-517-185-D (according to the Audi VW service)

Add to Compare Add to Wishlist

Description

In our catalogs, there are various items. bearings, "including this" conical metric XAA 32010 X. It has a larger mounting cut, as indicated by the Audi and Volkswagen services. The weight of the accessory is 0.37 kg. The outer diameter of the product reaches 80 mm, while the inner diameter is 50 mm. In the case of the basket, the manufacturer used reliable steel. Model XAA 32010 X was produced by the company TIMKEN. The company specializes in engineering bearings and power transmission systems. The enterprise has an international reputation, which is associated with the high quality of the accessories produced. In the case of Metric tapered bearings XAA 32010 X Every detail has been taken care of. This directly translates to the durability of the product.

A product born from experience

The dimensions of the offered bearing are 50 x 80 x 20 mm. It is a single-row model with a cylindrical type of bore. It is worth noting that it does not have a seal. XAA 32010 X belongs to the classic tapered roller bearings, where we find raceways on the rings, between which there are special rollers. In this case, the inner ring and the cage form a whole, while the outer elements remain separate. In the bearing TIMKEN The load is transferred along the line. This, in turn, remains positioned at the appropriate angle relative to the bearing. This is an essential element of the construction. In this way, the bearing can simultaneously transfer radial and axial loads. Of course, the final capabilities of the accessory are determined by the optimal working angle.

Product Details

BrandTIMKEN

Reference2392001B TIMKEN

Condition New

Data sheet
